Battery tray dimensions and fitment

Tags: #battery · #fitment

The X80 battery tray has flexible clearance for larger batteries. Interior tray dimensions: 190 × 260 mm base, up to 280 mm height available. Larger AGM batteries (70 Ah or more) fit with only slight modification, using cardboard or rubber shims as spacers to take up the extra room, and the clamping frame still secures the non-standard size. One owner successfully fitted and used a 70 Ah AGM (85D23L) battery, chosen over the stock size because the car sits unused ~4 days/week and AGM has lower self-discharge and faster charging; this setup has been tested working down to -33°C ¹²³⁴⁵.

Catalogue example in the tray's size class. A Russian-made Tyumen Battery Premium battery rated 64 Ah and 620 A, 242 x 175 x 190 mm with straight polarity, was listed on a marketplace in Oct 2025 (no price recorded) ⁶. Compare its 175 mm width with the 190 x 260 mm tray base above before ordering.

Media

Photo of an 85D23L AGM battery (70 Ah) installed in the tray with room around it

Diagram showing the battery tray's interior dimensions and attachment points
