Cruise control activation via Diagzon PRO

Tags: #cruise-control

Cruise control can be activated on trims that shipped without it — either with the physical steering-wheel buttons already present but unprogrammed, or (per the original request in this thread) without buttons installed at all 12. Method: use Diagzon PRO software to access the ECU and change the vehicle's configuration across multiple coding blocks to match a higher trim level's options; the poster who did this successfully didn't recall the exact block numbers afterward — he went through several blocks changing the "комплектация" (trim/equipment level) setting 34. Once coded correctly, a cruise-control menu option appears in the climate/comfort settings block, where it can be enabled 3.

Side effects observed. On a lower-trim monochrome-display car, after coding it to report a higher equipment level, the small dash screen began showing temperature values instead of bar-graph gauges, and the (physically absent/inoperative) parking-sensor display started appearing on screen during reverse — cosmetic side effects of the trim spoofing rather than malfunctions 56. The BSM/comfort-module block ("блок комфорта") is also involved in this coding process, not just the main ECU 78.

Warning: update Diagzon before changing settings. One attempt made without first updating the Diagzon software triggered multiple warning lights on the dash — the car remained drivable, but the coding session was clearly unstable without the update; updating the tool first is described as critical to avoid this ("чуть не окирпичел машину" — nearly bricked the car) 8.

Where this was done. The person who successfully performed and documented this procedure, Evgeny, is based in Saint Petersburg 9.

Confirmation from a separate case, with the operating sequence once enabled. A separate report confirms the same general path documented above: FAW X80 base/budget trims without cruise-control buttons can have the feature activated via diagnostic-software (RSM) configuration — but the physical steering-wheel buttons must first be installed and wired before activation, since the coding alone doesn't create the missing hardware. Once activated and the buttons are in place, operation is: at speed, press the on/off button on the right side of the wheel; use the joystick's minus (-) position to set the current speed as the cruise target; use the plus (+) position to increase the set speed 1011121314.

Media

Screenshot of the Diagzon PRO software interface used for the ECU coding

Screenshot of the Diagzon PRO software interface used for the ECU coding
